Solenoid Valve
SVM Series
MD MED developed and produced solenoid valve to build Hydraulic Motor Pump and Hydraulic System which prevented oil leak of the solenoid valve. In this way, solenoid valve could accomplish stable quality. Minimizes the impact that occurs when the solenoid valve opens and closes and stable operation is available even in high-pressure.
Smooth Operation
Prevention of Oil Leakage
Precise Test System
Standard type
– Specification
Combined optimal circuits
Non-oil leak product
Compact, Lightweight & Shockless structure
Easy installation and handling
Damper type
– Specification
Anti-shock Damper
Easy Installation and Handling
Various types of solenoid valves
– Specification
A variety of configurations according to customer’s requirement (There are 2p, 4p, 6p, 8p according to the number of stool)
Damping unit type
– Specification
Simple structure of damping unit-mounting type
Easy installation and handling
Helps smooth operation
Unit chair up and down available, slope cushioning effects
– Specification
(50/60Hz)
| Voltage | Rated Current | Wattage | Rated Time | |
| V | A | W | Min | |
| AC | 100 | 0.32/0.26 | 23/18 | 10 |
| 110 | 0.27/- | 29/- | ||
| 115 | 0.38/0.32 | 33/25 | ||
| 120 | -/0.32 | -/28 | ||
| 220 | 0.20/0.15 | 34/25 | ||
| 240 | 0.21/0.17 | 41/31 | ||
| DC | 12 | 1.28 | 15 | 1 |
| 24 | 0.63 | |||
+ Patent Pending: Hydraulic pressure buffer solenoid valve and method for operating the solenoid valve
+ Patent Pending: Solenoid valve assembly having damping unit
